Audison plug and play for a t6.1

[DarrylDunn]

I have emailed Audison without reply. But I know a few people have fitted Audison bits to their t6.1’s.

Does anyone know which plug and play cables I will need to connect a Prima 5.9 bit amp to the factory head unit?



[Skyliner33]

Match New VW Quadlock Fully Populated to ISO adapter - PP-AC-92b

New VAG Quadlock connector - Fully Populated. To Enable the connection of the MATCH amplifiers to the original cable harness of the vehicle without cutting any single wire. These adapters are combined with ISO connection cables for the Plug and Play Amplifiers.

www.raysmith.co.uk

Audison - Car Audio Amplifiers, Speakers, Processors

Car audio DSP amplifiers, speakers, and subwoofers. Go beyond the ordinary solutions that are where our instinct comes in.

www.audison.eu

Are you set on the APBit5.9?

How about:

Audison - Car Audio Amplifiers, Speakers, Processors

Car audio DSP amplifiers, speakers, and subwoofers. Go beyond the ordinary solutions that are where our instinct comes in.

www.audison.eu



[Dav-Tec]

What are you planning on powering off the bit amp. Hertz and Audison are our preferred brands the SR amps are more capable in terms of power and overall performance. I can supply you with the correct loom though.

Also are you aware that amp needs setting up with BitTune to work at it's optimum?



[DarrylDunn]

Thanks for getting back to me.
its not so much a case of being set on the Bit 5.9, I already own it.

I am intending to run a Voce 6.5, 3.0 + tweeter. I think I may have to pair my existing amp with an AP4d to be able to power this set up.

trying to get an answer from audison is like getting blood out of a stone



[Dav-Tec]

@DarrylDunn you will need the 4D to power it, you would run the 6.5” woofers bridged off the 4D. Channel 1 and 2 on the 5.9 for the VOCE mids 3” and 3 and 4 for the tweeters
