T6.1 Front Camera (R242) Wiring Diagram?
- Thread starter solutionz
- Start date
Have you checked through the 6.1 wiring diagram download section, I dont recall seeing a separate chapter for front camera so possible it’s within one of the other sections that’s already posted ?
I’m at work using my phone but can have a better look next time I’m on a pc
I’m at work using my phone but can have a better look next time I’m on a pc
It's a separate one - 84
Not that I can see.
I'm looking for one that shows the newer 6 wire T12 (8W0 972 112 A) plug pinout to R242 [2Q0 980 653 B], as opposed to the older 8 wire pinout.
1 - GREY
2 - ORANGE / BROWN
3 - (empty)
4 - (empty)
5 - BLUE
6 - BROWN / WHITE
7 - BROWN
8 - BLACK
9 - (empty)
10 - (empty)
11 - (empty)
12 - (empty)
Thanks, confirmed what I just measured.
OpenPilot / Comma.ai self driving on T6.1?
With the release of sleek new comma.ai comma three devkit I wonder if anyone has looked at installing it on their T6.1? (Unfortunately it doesn't look like T6 or lower are supported as they use "hydraulic power steering", but it looks like T6.1 should be as it uses electric). The VW Tiguan...
Does anyone know if it is possible to turn the rear camera on while driving to use to check the trailer? Seems it runs on the can system but would be great if there was a way.
Good question! There is some discussion here: Rear view camera without engaging reverse?
I think you may have to setup a manual switch to send the reverse signal to the headunit when driving.
@Robert states it's "easily achievable on T6 highline setup by tweaking coding and adaptations of the head unit", however I'm not sure what those adaptations are.
